Home » Products » Two Stage Blow Moulding Machine

Two Stage Blow Moulding Machine

Two Stage Blow Moulding Machine
Two Stage Blow Moulding Machine
Product Code : 07
Product Description

We are presenting for our customers a large gamut of Two Stage Blow Moulding Machine. Provided with highly functional components, our machinery is widely used for manufacturing small bottles. We manufacture and export our moulding machinery in a variety of specifications and production capacities. Apart from this, we can also customize our Two Stage Blow Moulding Machine according to the particular application requirements.

Features:



  • Integrated with wide mouth capability
  • Excellent production rates
  • Sturdily engineered

Further Details:

Fully Automatic Two Stage Pet perform straight Blow Moulding Machine

Technical Specifications

Description/Model

STA-500-B

STA-1000-B(HP)

STA-2000-B(HP)

STA-2000-J(HP)

Products Volume

30ml-500ml

50ml-1250ml

200ml-3000ml

200ml-3000ml

Mould Cavity

2 Cavity

2 Cavity

2 Cavity

2 Cavity

Production per hrs

1800 pcs-2000 pcs

1500 pcs-8000 pcs

1200 pcs-1500 pcs

600 pcs-800 pcs

Neck Dia Meter

19mm-28mm

25mm-28mm

28mm

46mm-800 pcs

Tie Bar distance

235mm

285mm

350mm

350mm

Mould Width

225mm

225mm

240mm

340mm

Mould Thickness

140mm

150mm

200mm

200mm

Cavity Distance

135mm

135mm

185mm

185mm

Clamping Stroke

100mm

150mm

150mm

150mm

Clamping Force

4 Tan

8 Tan

10 Tan

10 Tan

Operation

Hydro-Penu

Hydro-Penu

Hydro-Penu

Hydro-Penu

Electric Heater Power

12 K.W

15 K.W

18 K.W

18 K.W

Heater Type

Inferd Convair

Inferd Convair

Inferd Convair

Inferd Convair

Working Pressure

6 kg-8 kg

8 kg-10 kg

8 kg-10 kg

8 kg-10 kg

Blowing Pressure

15 kg-18kg

30 kg-35kg

30 kg-40kg

30 kg-40kg

Air Consumption

0.9M3/Min

1.M3/Min

1.M3/Min

1.02M3/Min

Staff Requirement

2 Person

2 Person

2 Person

2 Person

Air Compressor

20 HP-(LP), 52 CFM

20 HP-(LP), 42 CFM

20 HP-(LP), 52 CFM

25 HP-(LP), 52 CFM

Area Requirement

30 Mtr

30 Mtr

35 Mtr

35 Mtr

Machine Weight

1500 kg. Approx

1800 kg. Approx

2200 kg. Approx

2500 kg. Approx
